BWR-12/415-D12A-C

12V DC-DC Converter, 2x12V, 415mA, 10W, DIP, 1.5kV Isolation

Board mount DC-DC converter module with dual regulated outputs, providing 12V and -12V at 415mA each. Features 1.5kV isolation voltage, 84% efficiency, and a maximum output power of 10W. Operates from a 9V to 18V DC input range with a nominal input of 12V. Housed in a DIP package with gold contact plating, suitable for through-hole and surface mount applications. Compliant with RoHS standards and operating temperature range of -40°C to 100°C.

PackageDIP

MountingThrough Hole, Surface Mount

Power5W

Quick Jump:

Technical Specifications

Murata BWR-12/415-D12A-C technical specifications.

General

Package/Case	DIP
Contact Plating	Gold
Current - Output 1	415mA
Current - Output 2	415mA
Depth	50.8mm
Efficiency	84%
Height	9.53mm
Isolation Voltage	1.5kV
Lead Free	Lead Free
Max Input Voltage (DC)	18V
Min Input Voltage (DC)	9V
Max Input Voltage	18V
Min Input Voltage	9V
Max Operating Temperature	100°C
Min Operating Temperature	-40°C
Max Output Current	415mA
Max Output Power	10W
Max Power Dissipation	10W
Mount	Through Hole, Surface Mount
Nominal Input Voltage	12V
Nominal Output Voltage	-12V
Number of Outputs	2
Operating Supply Voltage	12V
Output Current	415mA
Output Power	5W
Output Voltage	12V
Packaging	Rail/Tube
Reach SVHC Compliant	No
RoHS Compliant	Yes
Series	BWR (10W)
Voltage - Output 1	12V
Voltage - Output 2	-12V
Width	25.4mm
