This 3-pin power connector features a zinc body with a silver-plated brass contact and a metal package. It has a current rating of 16A and a voltage rating of 50V. The connector is available in a bulk packaging quantity of 40 units.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Neutrik NC3MD-LX-BAG datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Neutrik NC3MD-LX-BAG technical specifications.
| Body Material | Metal |
| Package/Case | Metal |
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Silver |
| Current Rating | 16A |
| Flammability Rating | UL94 HB |
| Gender | Male |
| Material | Zinc |
| Number of Contacts | 3 |
| Number of Positions | 3 |
| Orientation | Vertical |
| Package Quantity | 40 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Series | DLX |
| Termination | Solder |
| Voltage Rating | 50V |
| Weight | 0.888904oz |
| RoHS | Compliant |
Download the complete datasheet for Neutrik NC3MD-LX-BAG to view detailed technical specifications.
The embedded preview will load automatically when this section scrolls into view.
