Technical Specifications
NXP BC638 technical specifications.
General
Package/Case
SOT-54
Collector Base Voltage (VCBO)
60V
Collector-emitter Voltage-Max
60V
Current Rating
-500mA
Emitter Base Voltage (VEBO)
5V
Gain Bandwidth Product
100MHz
hFE Min
25
Lead Free
Contains Lead
Max Collector Current
1A
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Power Dissipation
1W
Package Quantity
1000
Packaging
Tape and Reel
Polarity
PNP
RoHS Compliant
Yes
DC Rated Voltage
-60V
Compliance
RoHS
Compliant
Datasheet
NXP BC638 Datasheet
Download the complete datasheet for NXP BC638 to view detailed technical specifications.
