16-bit Digital Signal Processor (DSP) operating at 80MHz, featuring an ARM core architecture. This surface-mount component offers 64KB of FLASH memory and 9KB of RAM, with a 16-bit data bus width. It includes SPI, SCI, and EBI/EMI interfaces, 46 programmable I/Os, and 2 timers/counters. The device supports a supply voltage range of 2.25V to 2.75V, a maximum I/O voltage of 3.3V, and operates between -40°C and 85°C. This RoHS compliant component is packaged in LQFP.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP DSP56F826BU80E datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
NXP DSP56F826BU80E technical specifications.
| Package/Case | LQFP |
| Core Architecture | ARM |
| Data Bus Width | 16b |
| Density | 64KB |
| Frequency | 80MHz |
| Halogen Free | Halogen Free |
| Interface | SPI, SCI, EBI/EMI |
| Lead Free | Lead Free |
| Max Frequency | 80MHz |
| Max I/O Voltage | 3.3V |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 2.75V |
| Memory Size | 64KB |
| Memory Type | FLASH, |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.25V |
| Mount | Surface Mount |
| Number of I/Os | 46 |
| Number of Programmable I/O | 46 |
| Number of Timers/Counters | 2 |
| Oscillator Type | External |
| Package Quantity | 450 |
| Packaging | Tray |
| Peripherals | POR, WDT |
| Radiation Hardening | No |
| RAM Size | 9KB |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 56F8xx |
| Termination | SMD/SMT |
| Weight | 0.022942oz |
| RoHS | Compliant |
