8-bit microcontroller featuring 8KB OTP/EPROM memory and 304B RAM. Operates at a maximum frequency of 2MHz with an 8-bit address and data bus. Includes SPI and SCI interfaces, 24 I/Os, one SPI channel, one UART channel, and two timers/counters. Packaged in a PDIP for through-hole mounting, with an internal oscillator and peripherals like POR and WDT. Operating temperature range is -40°C to 85°C, with a maximum supply voltage of 5.5V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP MC68HC705C8ACP datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Address Bus Width | 8b |
| Package/Case | PDIP |
| Data Bus Width | 8b |
| Height | 4.06mm |
| Interface | SPI, SCI |
| Length | 52.45mm |
| Max Frequency | 2MHz |
| Max Operating Temperature | 85°C |
| Memory Size | 8KB |
| Memory Type | OTP, , EPROM |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of I/Os | 24 |
| Number of SPI Channels | 1 |
| Number of Timers/Counters | 2 |
| Number of UART Channels | 1 |
| Operating Supply Voltage | 5.5V |
| Oscillator Type | Internal |
| Packaging | Rail/Tube |
| Peripherals | POR, WDT |
| RAM Size | 304B |
| RoHS Compliant | No |
| Series | HC05 |
| Width | 14.22mm |
| RoHS | Not Compliant |
