SPST DIP switch featuring a slide actuator, through-hole mounting, and PC pin termination. Offers a 25mA contact current rating at 24VDC, with gold-plated contacts for enhanced durability. Designed for 1000 cycles of electrical and mechanical life, this RoHS compliant component operates within a temperature range of -20°C to 70°C. The 2.54mm terminal pitch and sealed DIP package ensure reliable performance.
PackageDIP
Current Rating25mA
MountingThrough Hole
Quick Jump:
Technical Specifications
Omron A6T-1102 technical specifications.
General
Actuator Length
0mm
Actuator Type
Slide (Standard)
Package/Case
DIP
Contact Current Rating
25mA
Contact Material
Gold
Contact Plating
Gold
Current Rating
25mA
Electrical Life
1000Cycles
Lead Free
Lead Free
Length
0.137inch
Max Operating Temperature
70°C
Max Voltage Rating (DC)
24V
Mechanical Life
1000Cycles
Min Operating Temperature
-20°C
Mount
Through Hole
Number of Circuits
1
Number of Positions
1
Orientation
Straight
Package Quantity
130
Packaging
Rail/Tube
Pitch
0.1inch
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
A6T
Terminal Pitch
2.54mm
Termination
PC Pins
Throw Configuration
SPST
DC Rated Voltage
24V
Washable
Yes
Compliance
RoHS
Compliant
