5-position, SPST rotary & slide actuator DIP switch featuring a straight, through-hole mount with PC pin termination. This washable slide actuator DIP switch operates at a 2.54mm terminal pitch and offers a 25mA current rating with a 24V DC voltage rating. Designed for a wide temperature range from -30°C to 85°C, it boasts an electrical life of 1000 cycles.
Current Rating25mA
MountingThrough Hole
Quick Jump:
Technical Specifications
Omron A6TN-5104 technical specifications.
General
Actuator Length
1mm
Actuator Type
Slide (Standard)
Current Rating
25mA
Electrical Life
1000Cycles
Length
0.576inch
Max Operating Temperature
85°C
Min Operating Temperature
-30°C
Max Voltage Rating (DC)
24V
Mount
Through Hole
Number of Circuits
5
Number of Positions
5
Orientation
Straight
Package Quantity
30
Packaging
Rail/Tube
Pitch
0.1inch
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
A6TN
Terminal Pitch
2.54mm
Termination
PC Pins
Throw Configuration
SPST
DC Rated Voltage
24V
Washable
Yes
Compliance
RoHS
Compliant
Datasheet
Omron A6TN-5104 Datasheet
Download the complete datasheet for Omron A6TN-5104 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
