SPDT microswitch with a pin plunger actuator, designed for general applications. Features a 2A contact current rating at 125VAC and 12VDC, with gold and silver contact material and gold plating. Offers a straight termination for solder mounting, a panel/chassis mount option, and a robust mechanical life of 1,000,000 cycles. Operating temperature range is -40°C to 85°C, with IP67, waterproof, and dust-tight ratings.
Package125
Current Rating2A
MountingPanel, Chassis Mount, Screw, Solder
Quick Jump:
Technical Specifications
Omron D2HW-C201H technical specifications.
General
Actuator Type
PIN PLUNGER
Package/Case
125
Contact Current Rating
2A
Contact Material
Gold, Silver
Contact Plating
Gold
Current Rating
2A
Depth
8.3mm
Electrical Life
100000Cycles
Length
18.5mm
Max Current Rating
2A
Max Operating Temperature
85°C
Max Voltage Rating (AC)
125V
Max Voltage Rating (DC)
42V
Mechanical Life
1000000Cycles
Min Operating Temperature
-40°C
Mount
Panel, Chassis Mount, Screw, Solder
Operating Force
0.75N
Orientation
Straight
Package Quantity
250
Packaging
Bulk
Ratings
IP67, Waterproof, Dust Tight
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
D2HW
Switch Function
On-Mom
Termination
Solder
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
12V
Weight
0.024692oz
Compliance
RoHS
Compliant
Datasheet
Omron D2HW-C201H Datasheet
Download the complete datasheet for Omron D2HW-C201H to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
