Technical Specifications
Omron E2E-X2Y1-M1 technical specifications.
General
Approvals
UL, CSA
Body Material
Brass
Package/Case
SOIC
Height
21mm
Length
53mm
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
30V
Min Supply Voltage
10V
Mount
Panel
Nominal Supply Current
13mA
Output
NO
Package Quantity
1
Ratings
IP67
Response Frequency
25Hz
RoHS Compliant
Yes
Sensing Distance
2mm
Sensing Method
Inductive
Series
E2E
Shielding
Shielded
Switching Current
200mA
Termination
Connector
Width
21mm
Compliance
RoHS
Compliant
Datasheet
Omron E2E-X2Y1-M1 Datasheet
Download the complete datasheet for Omron E2E-X2Y1-M1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
