The G6B-1174P-US12DC is a 12V non-latching relay with a coil current of 16.7mA and a coil power of 200mW. It has a contact current rating of 8A and is rated for a maximum operating temperature of 70°C and a minimum operating temperature of -25°C. The relay is PCB mount and has a switching current of 8A. It is rated for a voltage of 125V DC and 380V AC, and has an IP67 rating.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G6B-1174P-US12DC datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Application(s) | POWER |
| Coil Current | 16.7mA |
| Coil Power | 200mW |
| Coil Resistance | 720R |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12V |
| Contact Current Rating | 8A |
| Contact Material | Silver |
| Depth | 10mm |
| Height | 12.5mm |
| Length | 21.1mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Mount | PCB |
| Operate Time | 10ms |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Switching Current | 8A |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 380V |
| DC Rated Voltage | 125V |
| RoHS | Compliant |
