SPDT snap action switch featuring a simulated roller lever actuator. Rated for 3A at 125VAC and 30VDC, with a 125V maximum AC voltage rating. Offers a 100,000 cycle electrical life and 1,000,000 cycle mechanical life. Constructed with silver contacts and a straight orientation, it mounts via chassis, screw, or solder termination. Operates within a temperature range of -25°C to 85°C and is RoHS compliant.
Package125
Current Rating3A
MountingChassis Mount, Screw, Solder
Quick Jump:
Technical Specifications
Omron SS-3GL13P technical specifications.
General
Actuator Type
SIMULATED ROLLER LEVER
Package/Case
125
Contact Material
Silver
Current Rating
3A
Electrical Life
100000Cycles
Lead Free
Lead Free
Max Operating Temperature
85°C
Mechanical Life
1000000Cycles
Min Operating Temperature
-25°C
Max Voltage Rating (AC)
125V
Max Voltage Rating (DC)
30V
Mount
Chassis Mount, Screw, Solder
Number of Poles
1
Operating Force
0.5N
Orientation
Straight
Package Quantity
100
Packaging
Tray
Ratings
IP40
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
SS-P
Switch Function
On-Mom
Termination
Solder
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
30V
Compliance
RoHS
Compliant
Datasheet
Omron SS-3GL13P Datasheet
Download the complete datasheet for Omron SS-3GL13P to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
