Omron
V-10G-1C4-K
Switch Snap Action N.O./N.C. SPDT Pin Plunger 10A 250VAC 250VDC 248.57VA 0.98N Screw Mount Quick Connect
Current Rating6A
MountingChassis Mount
Quick Jump:
Technical Specifications
Omron V-10G-1C4-K technical specifications.
General
Current Rating
6A
Differential Travel
0.016inch
Electrical Life
300000Cycles
Max Operating Temperature
80°C
Mechanical Life
50000000Cycles
Min Operating Temperature
-25°C
Mount
Chassis Mount
Operating Force
1N
Operating Position
0.579inch
Overtravel
0.04inch
Package Quantity
100
Packaging
Bulk
Pretravel
0.047inch
Ratings
IP40
RoHS Compliant
Yes
Series
V
Switch Function
On-Mom
Termination
Quick Connect
Throw Configuration
SPDT
Voltage Rating (AC)
250V
DC Rated Voltage
30V
Compliance
RoHS
Compliant
Datasheet
Omron V-10G-1C4-K Datasheet
Download the complete datasheet for Omron V-10G-1C4-K to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
