Automotive motor driver IC in a 3-pin SOT-23 package. Features a maximum output current of 500mA and a rated current of 400mA, with a low-side output configuration. Operates from a 3V to 6V supply voltage, offering a maximum power dissipation of 225mW. Includes an On/Off interface and a fall time of 45ns. This surface mount component is halogen and lead-free, supplied in tape and reel packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Onsemi MDC3105LT1G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOT-23 |
| Fall Time | 45ns |
| Halogen Free | Halogen Free |
| Height | 0.94mm |
| Interface | On/Off |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 500mA |
| Max Power Dissipation | 225mW |
| Max Supply Voltage | 6V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| On-state Resistance-Max | 400MR |
| Output Configuration | Low Side |
| Output Current | 400mA |
| Output Voltage | 6V |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Rated Current-Max | 400mA |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 800uA |
| Width | 1.3mm |
| RoHS | Compliant |
Download the complete datasheet for Onsemi MDC3105LT1G to view detailed technical specifications.
The embedded preview will load automatically when this section scrolls into view.
These are design resources that include the Onsemi MDC3105LT1G
onsemi product discontinuance notice PD25141XB for various standard products. Last time buy date: June 15, 2023. Last ship date: December 15, 2023.
