Osram LGQ971 technical specifications.
| Package/Case | 0603 |
| Color | Green |
| Depth | 0.9mm |
| Forward Current | 20mA |
| Length | 1.7mm |
| Lens Style | Rectangular, Diffused, Colorless |
| Luminous Flux | 0.075lm |
| Luminous Intensity | 10mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -30°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Packaging | Cut Tape |
| Power Dissipation | 65W |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reverse Voltage | 12V |
| RoHS Compliant | Yes |
| Series | CHIPLED 0603 |
| Viewing Angle | 160° |
| Wavelength | 570nm |
| RoHS | Compliant |
