The SFH3710 is a surface-mount NPN LED emitter with a flat lens style and a wavelength of 570nm. It operates within a temperature range of -40°C to 85°C and has a collector emitter voltage of 5.5V. The device is RoHS compliant and available in cut tape packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Osram SFH3710 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Osram SFH3710 technical specifications.
| Package/Case | SMD/SMT |
| Collector Emitter Voltage (VCEO) | 5.5V |
| Lens Style | Flat |
| Max Collector Current | 20mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Packaging | Cut Tape |
| Polarity | NPN |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Viewing Angle | 60° |
| Wavelength | 570nm |
| RoHS | Compliant |
Download the complete datasheet for Osram SFH3710 to view detailed technical specifications.
