Compact programmable logic controller (PLC) with 8 DC inputs and 6 relay outputs, offering 14 total I/Os. Features 16K steps of memory and supports Ethernet networking. Operates on 24 VDC with a maximum common current of 5A and 2A per output point. Designed for DIN rail or surface mounting, with terminal block termination. Approvals include UL and CE, with an operating temperature range of 0°C to 55°C. Dimensions are 25mm length, 60mm width, and 90mm depth.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic AFP0RC14RS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CE |
| Depth | 90mm |
| Length | 25mm |
| Manufacturer Series | AFPOR Series |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | 0°C |
| Mount | DIN Rail, Surface Mount |
| Network Type | ETHERNET |
| Number of I/Os | 14 |
| Number of Inputs | 8 |
| Number of Outputs | 6 |
| Output Current | 2A |
| Output Type | RELAY |
| Reach SVHC Compliant | Unknown |
| Series | FP0R |
| Termination | Terminal Block |
| Width | 60mm |
| RoHS | Compliant |
