This Pan-Lug male header features a copper body with a tin plating, a brown color, and a copper contact with a tin plating. It has a length of 47.2mm and a depth of 15.2mm, with a tab thickness of 0.1 inch. The header is designed for free hanging and is available in bulk packaging. It is compliant with RoHS regulations and is not radiation hardened.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panduit LCD2-14AF-Q datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Body Material | Copper |
| Body Plating | Tin |
| Color | Brown |
| Contact Material | Copper |
| Contact Plating | Tin |
| Depth | 15.2mm |
| Gender | Male |
| Insulation | Non-Insulated |
| Length | 47.2mm |
| Mount | Free Hanging |
| Package Quantity | 1 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | Pan-Lug® |
| Tab Thickness | 0.1inch |
| Termination | Crimp |
| Weight | 0.832007oz |
| Wire/Cable Gauge | 2AWG |
| RoHS | Compliant |
