The PAN-TY PLT1M-C4Y cable tie is made from nylon and polyamide PA66 materials. It has a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. The tie is available in a bulk packaging quantity of 100 and is not halogen free. It has a thickness of 1.1mm and a weight of 1.44oz. The cable tie is unshielded and has a yellow color with a 22mm wire/cable diameter.
MountingFree Hanging
Quick Jump:
Technical Specifications
Panduit PLT1M-C4Y technical specifications.
General
| Body Material | Nylon |
| Bundle Diameter | 0.87inch |
| Color | Yellow |
| Depth | 4.6mm |
| Halogen Free | Not Halogen Free |
| Height | 0.154inch |
| Length | 99mm |
| Material | Nylon, Polyamide, PA66 |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Free Hanging |
| Package Quantity | 100 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Series | PAN-TY® PLT |
| Shielding | Unshielded |
| Thickness | 1.1mm |
| Weight | 1.44oz |
| Width | 2.5mm |
| Wire/Cable Color | Yellow |
| Wire/Cable Diameter | 22mm |
Compliance
| RoHS | Compliant |
Datasheet
Panduit PLT1M-C4Y Datasheet
Download the complete datasheet for Panduit PLT1M-C4Y to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
