The PAN-TY PLT1M-C6 cable tie is made from nylon and polyamide PA66 materials. It has a blue color and a bundle diameter of 0.87inch. The tie has a depth of 4.6mm and a height of 0.154inch. It is available in a package quantity of 100 and is not halogen free. The cable tie has a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It is designed for free hanging and is unshielded.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panduit PLT1M-C6 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panduit PLT1M-C6 technical specifications.
| Body Material | Nylon |
| Bundle Diameter | 0.87inch |
| Color | Blue |
| Depth | 4.6mm |
| Halogen Free | Not Halogen Free |
| Height | 0.154inch |
| Length | 99mm |
| Material | Nylon, Polyamide, PA66 |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Free Hanging |
| Package Quantity | 100 |
| Series | PAN-TY® PLT |
| Shielding | Unshielded |
| Thickness | 1.1mm |
| Weight | 1.44oz |
| Width | 2.5mm |
| RoHS | Compliant |
Download the complete datasheet for Panduit PLT1M-C6 to view detailed technical specifications.
