Feed-through terminal block with 2 positions and 10mm pitch, designed for right-angle wall mounting. Features a 32A maximum current rating and 500V voltage rating, accommodating wire gauges from 10AWG to 24AWG. Constructed with a grey, UL94 V-0 flammability rated housing, this lead-free and RoHS compliant component offers reliable solder termination. Approvals include CSA, cULus, CB, KEMA, and EAC.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Phoenix Contact 0708250 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | CSA, cULus, CB, KEMA, EAC |
| Color | Grey |
| Current | 30A |
| Current Rating | 32A |
| Depth | 25.5mm |
| Flammability Rating | UL94 V-0 |
| Height | 20.5mm |
| Housing Color | Grey |
| Lead Free | Lead Free |
| Length | 25.5mm |
| Max Current Rating | 32A |
| Max Supply Voltage | 500V |
| Mount | Wall |
| Number of Circuits | 2 |
| Number of Contacts | 2 |
| Number of Levels | 1 |
| Number of Poles | 2 |
| Number of Positions | 1 |
| Number of Positions Per Level | 1 |
| Number of Rows | 1 |
| Orientation | Right Angle |
| Packaging | Bulk |
| Panel Thickness | 4mm |
| Pitch | 10mm |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | CLIPLINE VDFK |
| Termination | Solder |
| Voltage | 300V |
| Voltage Rating | 500V |
| Weight | 0.143918oz |
| Width | 0.394inch |
| Wire Gauge (Max) | 24AWG |
| Wire Gauge (Min) | 10AWG |
| RoHS | Compliant |
