Barrier strip terminal block, 6 positions, 1 row, 1 deck, straight orientation, through-hole mount. Features a 10A current rating, 300V voltage rating, and 160V max supply voltage. Constructed with polyamide insulation and tin-plated copper contacts. Operates from -40°C to 100°C, with UL94 V-0 flammability rating. RoHS compliant and UL/CSA approved.
Voltage300V
Current10A
Voltage Rating200V
Current Rating13.5A
Quick Jump:
Technical Specifications
Phoenix Contact 1751280 technical specifications.
General
Approvals
UL, CSA
Color
Green
Contact Material
Tin
Current
10A
Current Rating
13.5A
Depth
7.3mm
Flammability Rating
UL94 V-0
Gender
Male
Height
7.3mm
Housing Color
Green
Insulation Material
Nylon
Lead Free
Lead Free
Length
7.3mm
Material
Polyamide
Max Current Rating
12A
Max Operating Temperature
100°C
Min Operating Temperature
-40°C
Max Supply Voltage
160V
Mount
Through Hole
Number of Circuits
6
Number of Contacts
6
Number of Levels
1
Number of Poles
6
Number of Positions
6
Number of Positions Per Level
6
Number of Rows
1
Orientation
Straight
Package Quantity
50
Packaging
Bulk
Pitch
3.5mm
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
COMBICON MKDS
Termination
Screw
Voltage
300V
Voltage Rating
200V
Weight
0.119861oz
Width
8.5mm
Wire Gauge (Max)
26AWG
Wire Gauge (Min)
16AWG
Wire/Cable Gauge
30AWG
Compliance
RoHS
Compliant
