Modular terminal block featuring 12 positions and 1 row, designed for 8A current and 160V DC rated voltage. This straight, female connector utilizes screw termination and accepts wire gauges from 14AWG to 30AWG. Constructed with a green polyamide housing and tin-plated contacts, it boasts UL94 V-0 flammability rating and is RoHS compliant. Approvals include UL, CSA, VDE, cULus, CB, and EAC.
Voltage300V
Current8A
Voltage Rating160V
Current Rating8A
Quick Jump:
Technical Specifications
Phoenix Contact 1827075 technical specifications.
General
Approvals
UL, CSA, VDE, cULus, CB, EAC
Color
Green
Contact Material
Tin
Contact Plating
Tin
Current
8A
Current Rating
8A
Depth
19.1mm
Flammability Rating
UL94 V-0
Gender
Female
Height
12.5mm
Housing Color
Green
Insulation Material
Nylon
Lead Free
Lead Free
Length
10.4mm
Material
Polyamide
Max Current Rating
8A
Mount
Free Hanging, Cable
Number of Circuits
12
Number of Contacts
12
Number of Levels
1
Number of Poles
12
Number of Positions
12
Number of Positions Per Level
12
Number of Rows
1
Orientation
Straight
Package Quantity
50
Packaging
Bulk
Pitch
3.81mm
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
MCVW
Termination
Screw
Voltage
300V
Voltage Rating
160V
DC Rated Voltage
160V
Weight
3.56267oz
Width
46.21mm
Wire Gauge (Max)
30AWG
Wire Gauge (Min)
14AWG
Wire/Cable Gauge
28AWG
Compliance
RoHS
Compliant
Datasheet
Phoenix Contact 1827075 Datasheet
Download the complete datasheet for Phoenix Contact 1827075 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
