14-position, 5.08mm pitch female terminal block with screwless spring cage termination. Rated for 320V and 12A, accepting wire gauges from 12AWG to 26AWG. Features tin-plated contacts and a green polyamide housing with UL94 V-0 flammability rating. Designed for panel mounting and free-hanging applications.
Voltage300V
Current10A
Voltage Rating320V
Current Rating12A
Quick Jump:
Technical Specifications
Phoenix Contact 1982017 technical specifications.
General
Color
Green
Contact Plating
Tin
Current
10A
Current Rating
12A
Flammability Rating
UL94 V-0
Gender
Female
Housing Color
Green
Material
Tin, Polyamide
Mount
Free Hanging
Number of Contacts
14
Number of Levels
1
Number of Positions
14
Number of Positions Per Level
14
Package Quantity
50
Packaging
Bulk
Pitch
5.08mm
RoHS Compliant
Yes
Series
COMBICON FKICS
Termination
Screwless
Voltage
300V
Voltage Rating
320V
Weight
0.842695oz
Wire Gauge (Max)
26AWG
Wire Gauge (Min)
12AWG
Compliance
RoHS
Compliant
