D-Subminiature connector module featuring 9 positions and 9 contacts. This female connector offers a 2.5A current rating and 125V voltage rating. Designed for DIN rail mounting, it utilizes screw termination and supports wire gauges from 16AWG to 26AWG. Operating within a temperature range of -20°C to 50°C, this green module has dimensions of 45mm depth, 42mm height, and 1.65 inches width.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Phoenix Contact 2962722 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Module |
| Color | Green |
| Contact Current Rating | 2.5A |
| Current Rating | 2.5A |
| Depth | 45mm |
| Gender | Female |
| Height | 42mm |
| Lead Free | Lead Free |
| Length | 2.13inch |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | -20°C |
| Mount | DIN Rail |
| Number of Contacts | 9 |
| Number of Positions | 9 |
| Packaging | Bulk |
| Series | VARIOFACE, UM |
| Termination | Screw |
| Voltage Rating | 125V |
| Voltage Rating (AC) | 125V |
| Weight | 2.680821oz |
| Width | 1.65inch |
| Wire Gauge (Max) | 26AWG |
| Wire Gauge (Min) | 16AWG |
| Wire/Cable Gauge | 16AWG |
| RoHS | Compliant |
