Modular terminal block featuring 2 positions and 2 poles, designed for 24A current rating and 600V voltage rating. This grey, general-purpose terminal block utilizes screw termination and supports wire gauges from 12AWG to 30AWG. Constructed with Nylon insulation and a UL94 V-0 flammability rating, it offers UL, CSA, and EAC approvals. The compact design measures 6.2mm in width and depth, with a height of 49.5mm.
Voltage600V
Current20A
Voltage Rating800V
Current Rating24A
Quick Jump:
Technical Specifications
Phoenix Contact 3001035 technical specifications.
General
| Approvals | UL, CSA, EAC |
| Color | Grey |
| Current | 20A |
| Current Rating | 24A |
| Depth | 6.2mm |
| Flammability Rating | UL94 V-0 |
| Height | 49.5mm |
| Housing Color | Grey |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Length | 42.5mm |
| Max Current Rating | 20A |
| Max Supply Voltage | 600V |
| Mount | Cable |
| Number of Circuits | 1 |
| Number of Contacts | 2 |
| Number of Levels | 1 |
| Number of Poles | 2 |
| Number of Positions | 2 |
| Number of Rows | 2 |
| Package Quantity | 50 |
| RoHS Compliant | Yes |
| Series | CLIPLINE UK |
| Terminal Width | 6.2mm |
| Termination | Screw |
| Voltage | 600V |
| Voltage Rating | 800V |
| Weight | 3.527lb |
| Width | 6.2mm |
| Wire Gauge (Max) | 30AWG |
| Wire Gauge (Min) | 12AWG |
Compliance
| RoHS | Compliant |
Datasheet
Phoenix Contact 3001035 Datasheet
Download the complete datasheet for Phoenix Contact 3001035 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
