Technical Specifications
Pomona Electronics 4108-14DB technical specifications.
General
Attenuation Value
14dB
Body Material
Brass
Contact Material
Copper, Brass
Contact Plating
Gold
Dielectric Material
Teflon
Impedance
50R
Lead Free
Lead Free
Max Operating Temperature
102°C
Min Operating Temperature
-55°C
Max Power Dissipation
2W
Orientation
Straight
Package Quantity
1
Primary Type
ATTENUATOR
Reach SVHC Compliant
No
Resistance
50R
RoHS Compliant
Yes
Tolerance
0.75%
Compliance
RoHS
Compliant
Datasheet
Pomona Electronics 4108-14DB Datasheet
Download the complete datasheet for Pomona Electronics 4108-14DB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
