Standard and High-Density Card Edge Connector, a 3-position, 3-contact male connector with straight orientation and solder termination. Features a 6A current rating and a 250V AC voltage rating, with a maximum AC voltage rating of 115.25kV. Panel mountable with snap-in installation, suitable for panel thicknesses up to 0.07 inches. Includes a fuse and boasts UL94 V-0 flammability rating. Approvals include UL, CSA, SEMKO, and VDE, with lead-free and RoHS compliant construction.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Qualtek 762-18/004 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, SEMKO, VDE |
| Package/Case | Module |
| Current | 6A |
| Current Rating | 6A |
| Flammability Rating | UL94 V-0 |
| Fuse | Yes |
| Gender | Male |
| Lead Free | Lead Free |
| Max Voltage Rating (AC) | 115.25kV |
| Mount | Panel, Snap in |
| Number of Contacts | 3 |
| Number of Ports | 1 |
| Number of Positions | 3 |
| Operating Frequency | N/A |
| Orientation | Straight |
| Package Quantity | 100 |
| Packaging | Bulk |
| Panel Thickness | 0.07inch |
| RoHS Compliant | Yes |
| Series | 762 |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 460mV |
| RoHS | Compliant |
