Technical Specifications
Samtec FTM-105-03-F-DV technical specifications.
General
Contact Finish - Mating
GOLD
Contact Material
Bronze
Contact Plating
Gold
Contact Shape
Square
Contact Type
Male Pin
Gender
Male
Insulation Color
Black
Insulation Material
Polymer
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Number of Contacts
10
Number of Positions
10
Number of Rows
2
Packaging
Rail/Tube
Pitch
1mm
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
FTM
Termination
Solder
Compliance
RoHS
Compliant
Datasheet
Samtec FTM-105-03-F-DV Datasheet
Download the complete datasheet for Samtec FTM-105-03-F-DV to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
