5-position, single-row socket strip with 2.54mm pitch. Features straight, through-hole mounting and solder termination. Constructed with bronze contacts and gold plating, it offers a maximum current rating of 7.1A and a voltage rating of 550V AC. The black housing operates within a temperature range of -55°C to 125°C. This RoHS compliant component is supplied in bulk packaging.
MountingThrough Hole
Quick Jump:
Technical Specifications
Samtec SLW-105-01-S-S technical specifications.
General
Color
Black
Contact Material
Bronze
Contact Plating
Gold
Depth
2.54mm
Gender
Receptacle
Housing Color
Black
Lead Free
Lead Free
Length
12.7mm
Max Current Rating
7.1A
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Max Voltage Rating (AC)
550V
Mount
Through Hole
Number of Contacts
5
Number of Positions
5
Number of Rows
1
Orientation
Straight
Package Quantity
1
Packaging
Bulk
Pitch
2.54mm
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
SLW
Termination
Solder
Width
2.54mm
Compliance
RoHS
Compliant
Datasheet
Samtec SLW-105-01-S-S Datasheet
Download the complete datasheet for Samtec SLW-105-01-S-S to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
