70-position, 2-row socket strip connector with 2.54mm pitch. Features tin-plated bronze fork-shaped contacts and a black glass-filled nylon housing. Designed for through-hole mounting with solder termination and a maximum operating temperature of 105°C. Offers a mated stacking height of 6.09mm and a voltage rating of 550V AC.
MountingThrough Hole
Quick Jump:
Technical Specifications
Samtec SLW-135-01-T-D technical specifications.
General
Contact Finish - Mating
TIN
Contact Material
Bronze
Contact Plating
Tin
Contact Shape
Square
Contact Type
Forked
Gender
Receptacle
Height
4.57mm
Housing Color
Black
Insulation Color
Black
Insulation Material
Glass
Lead Free
Lead Free
Length
88.9mm
Mated Stacking Heights
6.09mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole
Number of Contacts
70
Number of Positions
70
Number of Rows
2
Packaging
Bulk
Pitch
2.54mm
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
SLW
Termination
Solder
Voltage Rating (AC)
550V
Width
4.95mm
Compliance
RoHS
Compliant
Datasheet
Samtec SLW-135-01-T-D Datasheet
Download the complete datasheet for Samtec SLW-135-01-T-D to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
