50-position, single-row socket strip with 2.54mm pitch. Features gold-plated bronze contacts with a square, forked contact shape. Through-hole mounting with solder termination. Operating temperature range of -55°C to 125°C and a 550V AC voltage rating. Black glass-filled nylon housing.
MountingThrough Hole
Quick Jump:
Technical Specifications
Samtec SLW-150-01-G-S technical specifications.
General
Contact Finish - Mating
GOLD
Contact Material
Bronze
Contact Plating
Gold
Contact Shape
Square
Contact Type
Forked
Gender
Female
Height
4.57mm
Housing Color
Black
Insulation Color
Black
Insulation Material
Glass
Lead Free
Lead Free
Length
127mm
Mated Stacking Heights
6.09mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Through Hole
Number of Contacts
50
Number of Positions
50
Number of Rows
1
Packaging
Bulk
RoHS Compliant
Yes
Series
SLW
Termination
Solder
Voltage Rating (AC)
550V
Width
2.54mm
Compliance
RoHS
Compliant
Datasheet
Samtec SLW-150-01-G-S Datasheet
Download the complete datasheet for Samtec SLW-150-01-G-S to view detailed technical specifications.
