Surface mount socket strip featuring 4 positions and a 2mm pitch. This straight, top-entry receptacle offers a 3.9A current rating and 350V voltage rating. Constructed with copper contacts and gold plating, it operates within a -55°C to 125°C temperature range. The black housing ensures durability, and the component is RoHS compliant.
Voltage Rating350V
Current Rating3.9A
MountingSurface Mount
Quick Jump:
Technical Specifications
Samtec SMM-104-02-S-S technical specifications.
General
| Color | Black |
| Contact Material | Copper |
| Contact Plating | Gold |
| Contact Type | Female Socket |
| Current Rating | 3.9A |
| Depth | 2mm |
| Gender | Receptacle |
| Housing Color | Black |
| Lead Free | Lead Free |
| Length | 8mm |
| Max Current Rating | 3.9A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Voltage Rating (AC) | 350V |
| Mount | Surface Mount |
| Number of Contacts | 4 |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 2mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Tiger Eye™ SMM |
| Termination | Solder |
| Voltage Rating | 350V |
Compliance
| RoHS | Compliant |
