Samtec
TCSD-05-D-08.00-01-F-N
Cable Assembly 0.203m 28AWG 2mm 10 to 10 POS IDC Connector to IDC Connector F-F TIGER EYE™ Bulk
Quick Jump:
Technical Specifications
Samtec TCSD-05-D-08.00-01-F-N technical specifications.
General
Color
Grey, Black
Connector Type A
IDC
Connector Type B
IDC
Contact Material
Copper
Contact Plating
Gold
Gender
Female
Max Current Rating
1A
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Number of Positions
10
Number of Rows
2
Packaging
Bulk
Radiation Hardening
No
RoHS Compliant
Yes
Series
Tiger Eye™ TCSD
Shielding
Unshielded
Termination
IDT
Wire/Cable Gauge
28AWG
Wire/Cable Type
Flat Flex, Flat
Compliance
RoHS
Compliant
Datasheet
Samtec TCSD-05-D-08.00-01-F-N Datasheet
Download the complete datasheet for Samtec TCSD-05-D-08.00-01-F-N to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
