Unshrouded header with 6 positions and a 2.54mm pitch, featuring male pin contacts made of bronze with gold plating for superior mating. This right-angle, surface-mount component offers a maximum current rating of 7A and operates within a temperature range of -55°C to 125°C. The black polymer insulation meets UL94 V-0 flammability standards, and the component is RoHS compliant. Termination is via solder, with a depth of 10.92mm and length of 15.24mm.
MountingSurface Mount
Quick Jump:
Technical Specifications
Samtec TSM-106-01-S-SH technical specifications.
General
| Contact Finish - Mating | GOLD |
| Contact Material | Bronze |
| Contact Plating | Gold |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Depth | 10.92mm |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Housing Color | Black |
| Insulation Color | Black |
| Insulation Material | Polymer |
| Lead Free | Lead Free |
| Length | 15.24mm |
| Max Current Rating | 7A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Voltage Rating (AC) | 475V |
| Mount | Surface Mount |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Orientation | Right Angle |
| Packaging | Rail/Tube |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | TSM |
| Termination | Solder |
Compliance
| RoHS | Compliant |
Datasheet
Samtec TSM-106-01-S-SH Datasheet
Download the complete datasheet for Samtec TSM-106-01-S-SH to view detailed technical specifications.
