Unshrouded header with 6 positions and 1 row, featuring a 2.54mm pitch and straight, top-entry orientation. This male connector utilizes bronze contacts with gold plating, offering a 0.23-inch mating length and a 7.6A max current rating. The black housing is constructed for through-hole mounting with solder termination, operating within a -55°C to 125°C temperature range and supporting up to 550V AC.
MountingThrough Hole
Quick Jump:
Technical Specifications
Samtec TSW-106-07-S-S-LL technical specifications.
General
| Color | Black |
| Contact Material | Bronze |
| Contact Mating Length | 0.23inch |
| Contact Plating | Gold |
| Contact Type | Male Pin |
| Depth | 2.54mm |
| Gender | Male |
| Housing Color | Black |
| Length | 15.24mm |
| Max Current Rating | 7.6A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Voltage Rating (AC) | 550V |
| Mount | Through Hole |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Rail/Tube |
| Pitch | 0.1inch |
| RoHS Compliant | Yes |
| Series | TSW |
| Termination | Solder |
Compliance
| RoHS | Compliant |
Datasheet
Samtec TSW-106-07-S-S-LL Datasheet
Download the complete datasheet for Samtec TSW-106-07-S-S-LL to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
