The FN9260B-2/06 is a 250V AC rated terminal block with a current rating of 2A. It has a module package with a straight orientation and is terminated with solder. The terminal block operates between -25°C and 85°C. It has a length of 35mm and a depth of 60.3mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Schaffner FN9260B-2/06 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Schaffner FN9260B-2/06 technical specifications.
| Package/Case | Module |
| Current Rating | 2A |
| Depth | 60.3mm |
| Frequency | 400Hz |
| Gender | Female |
| Length | 35mm |
| Max Current Rating | 2A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (AC) | 250V |
| Number of Ports | 1 |
| Orientation | Straight |
| Termination | Solder |
| Voltage Rating (AC) | 250V |
| RoHS | Compliant |
