The 3RF23301BA04 is a 1-pole terminal block from Siemens, designed for industrial automation and control applications. It features a contact current rating of 30A and an isolation voltage of 600V. The block is mountable on DIN rail or panel and has a maximum operating temperature of 60°C. It is rated for IP20 and has a width of 45mm, a length of 45mm, and a height of 100mm. The block is part of the 3RF2330 series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 3RF23301BA04 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | 460 |
| Contact Current Rating | 30A |
| Depth | 140.5mm |
| Height | 100mm |
| Isolation Voltage | 600V |
| Length | 45mm |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Mount | DIN Rail, Panel |
| Number of Poles | 1 |
| Ratings | IP20 |
| Series | 3RF2330 |
| Termination | Screw |
| Width | 45mm |
| RoHS | Compliant |
