Siemens
3RT2017-1AP02
Contactor, 230 VAC 50/60 Hz, 3 NO, 1 break contact (NC), Screw Terminal, 3RT20171AP02, Siemens
Quick Jump:
Technical Specifications
Siemens 3RT2017-1AP02 technical specifications.
General
Coil Voltage (AC)
230V
Contact Current Rating
12A
Depth
73mm
Length
57.5mm
Max Operating Temperature
60°C
Min Operating Temperature
-25°C
Number of Poles
3
Ratings
IP20
Series
3RT2
Termination
Screw
Width
45mm
Compliance
RoHS
Not Compliant
Datasheet
Siemens 3RT2017-1AP02 Datasheet
Download the complete datasheet for Siemens 3RT2017-1AP02 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
