Voltage Rating400V
Current Rating25A
MountingDIN Rail
Power11kW
Quick Jump:
Technical Specifications
Siemens 3RW3026-1BB14 technical specifications.
General
Control Voltage
230V
Current Rating
25A
Length
151mm
Load Current
25A
Max Input Voltage
480V
Min Input Voltage
200V
Max Operating Temperature
60°C
Min Operating Temperature
-25°C
Max Supply Voltage (AC)
480V
Min Supply Voltage (AC)
200V
Max Supply Voltage
230V
Min Supply Voltage
110V
Mount
DIN Rail
Output Power
11kW
Overall Depth
125mm
Ratings
IP20
Reach SVHC Compliant
No
Series
3RW30
Voltage Rating
400V
Width
45mm
Compliance
RoHS
Compliant
Datasheet
Siemens 3RW3026-1BB14 Datasheet
Download the complete datasheet for Siemens 3RW3026-1BB14 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
