The 6ED1052-1FB00-0BA6 is an 8-input 4-output relay module designed for industrial automation and control applications. It operates on a 230V supply voltage and can handle up to 10A of output current. The module is mounted on a DIN rail and has an operating temperature range of 0°C to 55°C. It is rated for IP20 protection and is part of the LOGO! Series from Siemens.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 6ED1052-1FB00-0BA6 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Module |
| Depth | 55mm |
| Input Type | DIGITAL |
| Length | 55mm |
| Manufacturer Series | LOGO! 6 |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | 0°C |
| Mount | DIN Rail |
| Number of Inputs | 8 |
| Number of Outputs | 4 |
| Operating Supply Voltage | 230V |
| Output Current | 10A |
| Output Type | RELAY |
| Ratings | IP20 |
| Reach SVHC Compliant | No |
| Series | LOGO! Series |
| Width | 72mm |
| RoHS | Compliant |
Download the complete datasheet for Siemens 6ED1052-1FB00-0BA6 to view detailed technical specifications.
