The 6ED1055-1HB00-0BA0 is a 4-channel digital relay module from Siemens, designed for industrial automation and control applications. It operates within a temperature range of 0 to 55°C and is rated for use with a 24V supply voltage. The module is DIN rail mountable and features an IP20 rating for protection against solid particles. Compliance includes UL, CSA, and VDE approvals, but it is not SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 6ED1055-1HB00-0BA0 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, VDE, IEC |
| Package/Case | Module |
| Depth | 55mm |
| Input Type | DIGITAL |
| Length | 90mm |
| Manufacturer Series | LOGO |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | 0°C |
| Mount | DIN Rail |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| Operating Supply Voltage | 24V |
| Output Type | RELAY, Digital |
| Ratings | IP20 |
| Reach SVHC Compliant | No |
| Series | LOGO! |
| Width | 36mm |
| RoHS | Compliant |
