The Siemens 6ES7132-1BL00-0XB0 is a 32-channel digital output module designed for the SIMATIC ET 200L series. It measures 60.5mm in depth, 60mm in height, and 145mm in width, with a weight of 130g. The module operates within a temperature range of 0-40°C and provides 500mA of output current. It is suitable for industrial automation and control applications in fluid power and control systems, particularly in pneumatics.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Siemens 6ES7132-1BL00-0XB0 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Siemens 6ES7132-1BL00-0XB0 technical specifications.
| Package/Case | Module |
| Depth | 60.5mm |
| Height | 60mm |
| Length | 60mm |
| Manufacturer Series | SIMATIC ET 200L |
| Max Operating Temperature | 40°C |
| Min Operating Temperature | 0°C |
| Number of I/Os | 32 |
| Number of Outputs | 32 |
| Output Current | 500mA |
| Output Type | Digital |
| Weight | 130g |
| Width | 145mm |
| RoHS | Not Compliant |
Download the complete datasheet for Siemens 6ES7132-1BL00-0XB0 to view detailed technical specifications.
