The M145-0-0-13-0 panel meter features an LCD display and operates within a temperature range of 0 to 55°C. It has a high input impedance of 10MR and meets UL approval standards. With a compact design, the meter measures 72.1mm in length, 24mm in height, and 14.9mm in width, and weighs 10oz. It is designed for panel mounting and has a depth of 0.43inch.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Simpson Electric M145-0-0-13-0 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Accuracy | 0.04% |
| Approvals | UL |
| Common Mode Rejection Ratio | 90dB |
| Depth | 0.43inch |
| Display Type | LCD |
| Height | 24mm |
| Input Impedance | 10MR |
| Length | 72.1mm |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | 0°C |
| Mount | Panel |
| Operating Supply Current | 2mA |
| Series | M145 |
| Weight | 10oz |
| Width | 14.9mm |
| RoHS | Not Compliant |
