28-position, straight, inline plug connector with female socket contacts. Features a 13A current rating and 2kV voltage rating. Constructed with a thermoplastic shell and glass/thermoplastic body material, it offers a -55°C to 125°C operating temperature range and IP65 sealing. Crimp termination, gold contact material, and UL94 V-0 flammability rating ensure reliable performance.
Sign in to ask questions about the Souriau UTG620-28SN datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Souriau UTG620-28SN technical specifications.
| Approvals | UL |
| Body Material | Glass, Thermoplastic |
| Package/Case | Metal |
| Color | Black |
| Contact Gender | Female |
| Contact Material | Gold |
| Contact Type | CRIMP |
| Current Rating | 13A |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Lead Free | Lead Free |
| Length | 24.9mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Free Hanging, Cable |
| Number of Contacts | 28 |
| Number of Positions | 28 |
| Orientation | Straight |
| Package Quantity | 25 |
| Packaging | Bulk |
| Primary Type | Sealed |
| Radiation Hardening | No |
| Ratings | IP65 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | UTG |
| Shell Material | Thermoplastic |
| Shell Size | 20 |
| Termination | Crimp |
| Voltage Rating | 2kV |
| RoHS | Compliant |
