Technical Specifications
Stmicroelectronics 74AC00M technical specifications.
General
Package/Case
SO
High Level Output Current
-24mA
Logic Function
OR GATE
Low Level Output Current
24mA
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Max Supply Voltage
6V
Min Supply Voltage
2V
Number of Elements
4
Number of Gates
4
Number of Input Lines
2
Number of Output Lines
1
Package Quantity
50
Packaging
Rail/Tube
Propagation Delay
9.5ns
RoHS Compliant
No
Series
74AC00
Turn-On Delay Time
24ns
Compliance
RoHS
Not Compliant
Datasheet
Stmicroelectronics 74AC00M Datasheet
Download the complete datasheet for Stmicroelectronics 74AC00M to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
