Technical Specifications
Stmicroelectronics HCF4094BM1 technical specifications.
General
| Package/Case | SOP |
| Logic Function | Shift Register, Latch |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 20V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of Channels | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Input Lines | 3 |
| Number of Output Lines | 3 |
| Output Type | 3-STATE |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Propagation Delay | 190ns |
| RoHS Compliant | Yes |
| Series | HCF4094 |
| Technology | CMOS |
| Turn-On Delay Time | 840ns |
Compliance
| RoHS | Compliant |
Datasheet
Stmicroelectronics HCF4094BM1 Datasheet
Download the complete datasheet for Stmicroelectronics HCF4094BM1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
