1.8V fixed positive LDO regulator with 1.2V dropout voltage, capable of delivering up to 1.3A output current. Features a 1% accuracy and a PSRR of 75dB. Designed for surface mount applications in a TO-252-3 (DPAK-3) package. Operates from -40°C to 125°C with a maximum input voltage of 15V. This lead-free, RoHS compliant component offers a single positive output.
PackageTO-252-3
MountingSurface Mount
PolarityPositive
Quick Jump:
Technical Specifications
Stmicroelectronics LD1117DT18C technical specifications.
General
Accuracy
1%
Package/Case
TO-252-3
Input Bias Current
5mA
Lead Free
Lead Free
Max Input Voltage
15V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
1.3A
Min Output Voltage
1.8V
Max Power Dissipation
12W
Mount
Surface Mount
Number of Outputs
1
Number of Regulators
1
Output Configuration
Positive
Output Current
800mA
Output Type
Fixed
Output Voltage
1.8V
Package Quantity
75
Packaging
Rail/Tube
Polarity
Positive
Power Supply Rejection Ratio (PSRR)
75dB
Quiescent Current
10mA
Radiation Hardening
No
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
Stmicroelectronics LD1117DT18C Datasheet
Download the complete datasheet for Stmicroelectronics LD1117DT18C to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
