Stmicroelectronics
LD29300V33
3.3V FIXED POSITIVE LDO REGULATOR, 0.7V DROPOUT, SFM3, ROHS COMPLIANT, TO-220, 3 PIN
PackageTO-220-3
MountingThrough Hole
PolarityPositive
Quick Jump:
Technical Specifications
Stmicroelectronics LD29300V33 technical specifications.
General
Accuracy
1%
Package/Case
TO-220-3
Dropout Voltage
400mV
Input Bias Current
20mA
Max Input Voltage
30V
Min Input Voltage
2.5V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
3A
Mount
Through Hole
Number of Outputs
1
Number of Regulators
1
Output Current
3A
Output Type
Fixed
Output Voltage
3.3V
Package Quantity
50
Packaging
Rail/Tube
Polarity
Positive
Quiescent Current
50mA
Radiation Hardening
No
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
Stmicroelectronics LD29300V33 Datasheet
Download the complete datasheet for Stmicroelectronics LD29300V33 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
