PackageSOT-23-5
MountingSurface Mount
PolarityPositive
Quick Jump:
Technical Specifications
Stmicroelectronics LD2981ABM18TR technical specifications.
General
| Accuracy | 0.75% |
| Package/Case | SOT-23-5 |
| Input Bias Current | 80uA |
| Lead Free | Contains Lead |
| Max Input Voltage | 16V |
| Min Input Voltage | 2.5V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 100mA |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Regulators | 1 |
| Output Current | 100mA |
| Output Type | Fixed |
| Output Voltage | 1.8V |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Polarity | Positive |
| Quiescent Current | 100uA |
| Radiation Hardening | No |
| RoHS Compliant | No |
Compliance
| RoHS | Not CompliantNo |
Datasheet
Stmicroelectronics LD2981ABM18TR Datasheet
Download the complete datasheet for Stmicroelectronics LD2981ABM18TR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
