Voltage Mode PWM controller IC, designed for DC/DC conversion. Features a 49% maximum duty cycle, 500kHz maximum operating frequency, and a 5.2V output voltage. Operates from 0°C to 70°C with a maximum supply voltage of 35V and a typical supply current of 14mA. Includes clock synchronization, two outputs, a single output phase, and synchronous rectification. Packaged in SO for surface mounting, supplied on tape and reel, and is RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Stmicroelectronics SG3525AP013TR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SO |
| Clock Sync | Yes |
| Duty Cycle | 49% |
| Fall Time | 50ns |
| Lead Free | Lead Free |
| Max Duty Cycle | 49% |
| Max Frequency | 500kHz |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Current | 20mA |
| Max Supply Voltage | 35V |
| Mount | Surface Mount |
| Number of Output Phases | 1 |
| Number of Outputs | 2 |
| Operating Supply Current | 14mA |
| Output Configuration | Positive |
| Output Current | 400A |
| Output Voltage | 5.2V |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Synchronous Rectifier | Yes |
| Topology | Push-Pull |
| Weight | 0.007079oz |
| RoHS | Compliant |
